Description

CMI manufactures economical cartridge filter vessels in 3,5 and 7 rounds in both SS304 or SS316L. We are able to supply for all industrial standard DOE and SOE configuration of up to 40inch length. They are vertical design for general purpose applications in all industries.

They can be applied in many industrial applications with liquid of low to medium viscosity.
The structure is stable and can be calculated and constructed acc. to ASME Section VIII, Division 1.

Features

－V clamp closure for easy change out
－Economic design
－Length can be up to 40inch
－Fix perfectly with all standard filter cartridges
－Can be assembled with all standard filter cartridges
－Easy cleaning of inner & outer surface

Data & Specifications:

－Length: 10inch to 40inch
－Connection: BSP, NPT, ANSI, DIN
－Design Pressure: 6bar
－Design Temp: 120 deg C
－Material: SS304 & SS316L
－Gasket: Buna, EPDM, Viton
－Surface Treatment: E-polishing or Shot blasting
